Name: 82 Head
Brand: onefarmtest
Price: 23000.00 NZD
Availability: InStock

Is the Maxxus 82 Head Yard right for you?

This is a popular yard for those dealing with mobs of 50 head at a time in the yards. Or you may be a dairy farm needing a set of satellite yards for managing 100 head mobs of calves.

You’ve got three genuine drafting options, two internal and one external.

The main race is 6m long, so you’re able to hold 3 adult cattle or 6-7 calves in the race at a time.

As with the 62-head yard, this design flows smoothly from pen to pen.
We’ve situated man gates throughout the yard so the operator is able to move between pens with ease. If you need to get out of the way quickly, you can!

If you’re wanting this yard installed by one of our preferred yard builders, please let us know.

Holding Capacity: 82
Comfortable Capacity: 55
Working Pens: 4
Race Length: 6m (holds 5 cattle)
Drafting options: 3

10 Year Warranty

On the hot-dip galvanised steel

Designed in NZ

With high quality steel in conjunction with our engineers and valued customer feedback

Free Delivery

to your nearest Mainfreight

Steel Warranty

18-month structural warranty on all steel.

In-depth walk-through of a Maxxus 82 Head Yard

.

WATCH RAMP WALKTHROUGH WATCH

Yard Specs

With the MAXXUS range, we maximize

As the owner of a lifestyle block, you need a yard that you can move around and grow to adapt to your stock numbers. You should also be able to run cattle and sheep through one set of yards rather than specific yards for each - that’s wasted money and more space taken up than what’s required.

Panel Heights

Maxxus Yard Panels are 1.8m tall with 7 rails

Panel Lengths

We use a range of panel lengths to create a shape of yards from 0.8m to 2.1m

Gate Heights

Maxxus Gates are 2.2m tall with 7 rails

Gate Lengths

We have a wide range of gate lengths including Man Gates at 0.8m and entry gates at 2.1m. We do have entry gates at 2.6m too if required.

Gate (Post Specs)

Gate posts are 50x50x2.5mm

Gate (Rail Specs)

Gate rails are 66x47x2mm

Panel (Post Specs)

Panel Posts are 50x50x2mm

Panel (Rail Specs)

Panel rails are 66x47x2mm

Sheep Friendly

The bottom three spacings on our new range is 120mm, 150mm, 180mm.

HDG After Welding

Every Yard is full hot dipped galvanized after welding

Slam Latches

All gates use slam latches.

Rattle Free Hold

All connections between panels and gates use a ‘Clamp on Pin’. The clamp ‘squeezes’ panel/gate posts, and the pin sits snug in the lug to ensure a ‘rattle free’ hold

Ground Bracing

All yards are braced in the ground via 500m ribbed Ground Spikes (non-concrete) or Concrete Screws (on concrete)

Our commitment to durability

Steel Depth = Strength

When cattle are putting pressure on yards, it is ‘lateral pressure’. For this reason our cattle rail is 47mm deep which is 15% stronger than most alternatives.

We go deeper rather than higher as cattle push up against the rails, they don’t walk on top of them from our experience.

Why steel over wood?

Five reasons to go steel over timber

01

Durability & Longevity

Steel lasts significantly longer than timber. They don't rot and warp, meaning they handle the elements and livestock pressure for decades with minimal maintenance.

02

Almost Zero Maintenance

Timber yards require regular upkeep - repairs and replacements. Steel yards, especially hot dipped galvanised ones, require little to no maintenance beyond occasionally greasing your slam latches.

03

Easy Assembly & Portability

Our steel yards are modular and therefore, a lot quicker to set up then timber yards. They're also portable, so can be moved easily to from block to block if necessary.

04

Flexibility of Change

You're not confined by your original decision. You may need to expand your yard, or perhaps you want to move the entry gate to your yards because they're not flowing quite right. Easy with steel! Tough work with timber! Flexibility as your needs change!

05

Resale Value

Because they last longer, require less upkeep and are portable, steel yards hold their value better, making them a solid investment if you ever need to sell or upgrade.

Minimal Noise with Maxxus

Steel yards rattle like a bitch? Not when they are Maxxus yards

As the owner of a lifestyle block or smaller yard, investing in yards, whether steel or timber, it’s a sizeable investment, so we recommend doing your due diligence. When it comes to steel yards, yes some brands do rattle. Rattly yards produce unnecessary noise that wind cattle up and make basic cattle handling tasks a nuisance. Not to mention getting your cattle into the yards next time being that much harder! We’ve solved this with quite a simple fix – our Anti-Rattle Connection Clamps.

Snug lug fitting

Firstly, the steel rod on our clamps sits nice and snug in the lug fitting on each panel. We allow for ~0.5mm of clearance, so when you’re assembling your yard you’ll find that they ‘just’ fit.

Flush clamp section

Secondly, the ‘clamp’ section fits around the steel posts of each panel or gate, nice and flush. Using a wrench or ideally a rattle gun, these are tightened to ‘pinch’ the steel posts, removing any rattle.

It’s a simple and cost effective solution which so many of our clients rate highly.

Even Ben Mcilwrick (more commonly known at Ben The Fencer) who’s built plenty of timber yards in his time was amazed at how effective our anti-rattle clamps are. He’s recently built a set of our MAXXUS yards for one of his clients in Rangiora, North Canterbury

We were both blown away with how quiet and solid they were...

We were really unsure about steel yards for a couple of reasons - we’d heard they rattled and weren’t as solid as timber yards through other friends that have used steel in the past. Although Jack ensured that they’d mitigated those problems through their special clamping system and extra bracing, we went and had a look at a similar sized set of yards which really impressed us. Now that they’re standing, our fencer came to build some post and rail fencing to feed cattle into the yards. Even he was blown away with how solid they are with all the bracing and ground spikes supplied.

Ben the Fencer

Maximising Yard Strength

Are they actually solid enough?

If you're only running a handful of tame cattle in a small yard, then the Overhead Bracing isn't a necessity - perhaps save the money. You can buy them later on if need be.

If you're running bigger cattle, and in mobs of 10 plus, the Overhead Braces are good for 'tying' the yard structure together.

We brace any junctions that are close to 90 degrees to effectively ‘lock’ panels and gates in place. Think of it as “united we stand.” When all panels and gates are braced together, they’re much stronger, and therefore far more capable of withstanding stock pressure than without any bracing.

The Overhead Bracing maximizes strength and structural integrity

This allows you you to manage your herd in a solid set of yards that don’t move or rattle unnecessarily. They really are a key cog in the wheel!

.

Maximised strength

.

Minimised rattle

.

Solid yards for handling all stock classes on your lifestyle block

A Secure Foundation

How we maximise durability

9 times out of 10, MAXXUS yards go on a gravel type pad or just grass, in which case our 500mm Ground Spikes are a great addition.

If you do opt for a concrete pad for your MAXXUS yard, then concrete screws are the way to go. Otherwise if you're on grass or gravel, our 500mm Ground Spikes a great for locking panels and gates in place.

They’re 500mm long, and they’re ribbed, making sure that when they’re driven into the ground, they lock your panels and gates into place.

Each panel has a ‘footing’ at either end with x2 holes. These footings provide not only anchor points for the Ground Spike, but also increased stability for your MAXXUS panels and also gates. 1 x Ground Spike at each end of a panel/gate is plenty.

You’ll need a sledge hammer to get all of these in place, and we recommend doing your stretches before and after!

Want to see how it works?

HERE’S JOE THUMPING A GROUND SPIKE 500mm DEEP

.

Watch the video

Loading Ramps with MAXXUS

How much are they and why do I need a loading ramp?

There are typically two instances where you don’t need a Loading Ramp and that is a) if you opt for home-kill or b) if your site is set up for a loading bank (i.e. your yards are situated on a rise which a stock truck can back up to).

In most other cases you’ll need a loading ramp.

Our MAXXUS Loading Ramp has been designed to cater to your typical lifestyle farmer - you may need to load the back of a ute, or perhaps a trailer, or a proper stock truck. Due to the height-adjustable design, you can load pretty much anything!

The ramp has a range of height settings, so there really isn’t a scenario where you’ll get caught out!

See our height-adjustable MAXXUS Loading Ramp in action

.

Watch Video WATCH

Installation Process

How a MAXXUS yard comes together

SKIP TO FAQs

.

Select the right Maxxus yard design

Find a design that suits your stock numbers and site. Making sure you can work safely in the yards.

01

Left hand or right hand operation?

The difference between left hand and right hand is shown in the image carousel at the top of the page. This determines which way gates swing throughout your yard and which way it flows.

02

Pay your deposit

Pay the 50% deposit and wait 4-6 weeks for your yard to be delivered if they’re not already in stock.

If you need a set in a hurry, let us know and we'll see what we can do.

03

Prepare your yard site

You can just stand the yards up on grass. Otherwise if you want to put a gravel type base down, use the pad measurements provided.

04

Assembly plans delivered

We send you your assembly/site plans. Super easy to follow.

05

Yard is delivered

Yards are delivered to your nearest Mainfreight for free. We can organise hiab delivery direct to site, please ask and we can send you a quote.

06

Build your yard

If you want a Onefarm certified yard builder to build your yards, rough estimates are here.

07

Frequently Asked Questions

Either using 500mm Ground Spikes (if your yards are on a gravel pad or grass) or Concrete Screws (if you're putting your yards on a concrete pad). The Ground Spikes are $9+GST each. We recommend 2 per panel. For small yards (like our 6-head or 12-head), where you're only running a few tame cattle through them, there's no need for Ground Spikes—the yard itself is self-supporting enough.

If you’re buying a Loading Ramp with your package, then that’s the biggest pallet of the lot. It measures 2.7m x 2.7m, so you’ll need to make sure your trailer can handle that safely. If you’re not buying a Loading Ramp, then the pallets measure 2.2m x 2.2m. For yards 48-head and up, we recommend talking with your local transport provider to pick up your yards from your nearest Mainfreight and deliver direct to your site.

All yards come with a 10-year warranty on the hot-dipped galvanising. All steel comes with an 18-month structural warranty.

Yes, we’ve kept sheep in mind when we designed the Maxxus range, so lifestyle blocks can have one set of handling yards for both sheep and cattle. The bottom few gaps between rails are 150mm, 160mm and 190mm.

A flat surface is ideal; however, our anti-rattle connection clamps are designed with enough flexibility to accommodate some uneven ground. A mild slope in the paddock won't be an issue. Steeper slopes do pose challenges during assembly. Many of our customers choose to lay a level pad before setting up their yard or select a suitable site with minimal slope. If necessary, adding gravel afterward to help level the area is a simple solution.
